Only for professionals

DIN 6796

Conical spring washers for threaded connections
Material: Spring steel | Surface: mechanically zinc-plated

Diameter (d)

Packingunit

For further information please contact us.
Item no.: 6796FSTMZ10

Description

Item no.: 6796FSTMZ10
DIN 6796 | steel | spring steel | mechanically zinc-plated | Cr(VI) - free

Diameter: 10.5

technical details

Read on Hide
Application Joining by bolt, joining by stud, joining by screw
Cr(VI) Note Cr(VI)-free
Diameter (d) 10
Diameter (d2) 23
Diamter (d1) 10.5
For thread M10
Form Round
h max. 3,2
h min. 2,8
Installation method Assembly by hand
Material Spring steel
Risk hydrogen embrittlement
RoHS conformal
s 2,5
Surface mechanically zinc-plated

Downloads

You can download CAD-files from our catalog on partcommunity: To Böllhoff partcommunity
Title Language Version File Download
Fastening and assembly technology: Products and services English 1180/21-V1-EN (WBH) 8.79 MB / PDF
Data sheet: Technical information and dimensions of the product English 02/2023 117.40 KB / PDF
Böllhoff bulletin: Changeover to Cr6+-free protective zinc layers for fasteners English 1622/15.02 894.98 KB / PDF
